DIMENSIONS (Metal box controller)
Dim "A" Dim "B" Dim "C" Dim "D" Dim "E" Dim "F"
9.00"
228.6 mm
7.75"
196.8 mm
10.00"
254.0 mm
5.25"
133.3 mm
10.75"
273.0 cm
11.50"
292.1 mm
Tolerance: +- 0.10 inches / 02.5 cm
