Keyboard/Mouse Connector
Connector type: 2x4 8-pin header, 2.54mm pitch
Connector location: JP2
Pin
Definition
Pin
Definition
1
VCC5
2
VCC5
3
KDAT
4
MDAT
5
KCLK
6
MCLK
7
GND
8
GND
1
7
2
8
GAL Programming Connector
Connector type: 1x6 6-pin header, 2.54mm pitch
Connector location: J3
1
6
Pin
Definition
Pin
Definition
1
3VSB
2
GND
3
GAL1_TCK
4
GAL1_TDO
5
GAL1_TDI
6
GAL1_TMS
