NISE 4000 User Manual
Chapter 2: Jumpers and Connectors
COM1 TX Setting
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP6
COM1 RX Setting
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP7
Pin
Definition
1
COM1_TXLED (GPIO)
2
COM1_TX_LED
3
COM1_TXD (SIO)
Pin
Definition
1
COM1_RXLED (GPIO)
2
COM1_RX_LED
3
COM1_RXD (SIO)
1
3
1
3
