S.0ta/S.0ts

Alloy/Silk Dome

Tweeter

HEX™ Engineering Detail Drawings

• Mounting Depth

• Cutout Diameter

• Overall Diameter

• Recess Depth

• All Dims in mm[IN.]

Ш48

[Ш1.95]

Ш49

[Ш1.87]

Ш58

[Ш2.25]

18

[.70]

14

[.55]

25

[.97]

Tweeter

Only

Tweeter w/

Surface Mount

Tweeter w/

Flush Mount
