Page 8: Connection
Connector pin out
Pin
1
2
3
4
Signal
TX_D1+
TX_D1-
RX_D2+
Description
5
6
7
8
RX-D2-
G
G
Ground
Ground
Cat5 Cable Color
White / Orange
Orange
White / Green
Blue
White / Blue
Green
White / Brown
Brown
RJ-45
1
8
CUEnet (LAN)
RS-232 Connector
Touch controller serial connection. Elo TouchSystem compatible controllers supported.
PS/2 Connector
PS/2 pointing device connection, PS/2-keyboard-mouse (Y-cable) must be used!
VGA Connector
VGA monitor connection
4.3.
Connection
User Manual touchCUE-V /i
www.cuesystem.com
Page 8 of 27
