LS-373 User’s Manual

-

15

-

2.3

2.3.1

Connector

Function

Remark

CPU

Socket 478 for socket-P CPU

SO-DIMM

204-pin DDR3 SO-DIMM socket

SATA1/2

7-pin Serial ATA connector

DC_IN

DC 12V input connector

DC_OUT

4-pin power output connector

CN_AUDIO

5 x 2-pin audio connector

CD_IN

4-pin CD-ROM audio input connector

CN_DIO

6 x 2-pin digital I/O connector

CN_USB1/2

5 x 2-pin USB connector

CPUFAN

4-pin CPU cooler fan connector

SYSFAN

3-pin system cooler fan connector

CN_HDTV

5 x 2-pin HDTV interface

CN_LVDS

20 x 2-pin LVDS connector

CN_INV

5-pin LCD inverter connector

CN_IR

5-pin IrDA connector

JFRNT

14-pin front panel switch/indicator connector

MINIPCI

124-pin Mini PCI socket Type IIIA

MINI_CARD

52-pin PCI Express mini card

CN_COM2 9-pin

RS422/485/232

JAT

Power mode select

JCSEL1
JCSEL2

CN_COM2 RS-232 RS422 RS485 Setting /
CN_IR IrDA Setting

JRTC

CMOS Operating/Clear Setting

2.3.2

Connector

Function

Remark

RJ45_1/2

Two RJ45 LAN Ports

SPDIF

SPDIF digital audio output Port

PS2

PS/2 keyboard and mouse Port

CRT

Analog DB15 VGA Port

COM1

DB9 RS232 COM Port
