COMMELL FS-A71 User Manual
Page 15
FS-A71 User’s Manual
-
14
-
2.4
2.4.1
The board comes with the socket478 for Intel
®
Core 2 Duo/Celeron M
socket-P
processor
only it supports new generation of Intel
®
Core 2 Duo/Celeron M
socket-P
processor with
533/667/800MHz of front side bus and 4MB L2 cache. Please follow the instruction to install
the CPU properly.
1. Use the flat-type
screw drive to unlock
the CPU socket
Unlock way
Check point
3. Lock the socket
2. Follow the pin direction to install
the processor on the socket
