FS-A73 User’s Manual

14

2.3

2.3.1

Connector

Function

Remark

CPU

Socket rPGA988A for PGA988 CPU

SO-DIMM1/2

204 -pin DDR3 SO-DIMM socket

SATA1/2/3/4/5/6 7-pin

Serial ATA connector

IDE

40-pin primary IDE connector

CN_AUDIO

5 x 2-pin audio connector

CD_IN

4-pin CD-ROM audio input connector

CN_DIO

6 x 2-pin digital I/O connector

CN_USB 1/2/3/4

5 x 2-pin USB connector

CPUFAN

4-pin CPU cooler fan connector

SYSFAN

3-pin system cooler fan connector

CN_LVDS

20 x 2-pin LVDS connector

CN_DVI

13 x 2-pin DVI connect

CN_INV

5-pin LCD inverter connector

CN_IR

5-pin IrDA connector

JFRNT

14-pin front panel switch/indicator connector

MINI_CARD

52-pin Mini-PCIE socket

CN_COM1/2/3/4/5/6

9-pin RS232

JAT

3-pin Power mode select

JPT1/2

3-pin Com Voltage Setting

CN_LPT

13 x 2-pin printer connector

2.3.2

Connector

Function

Remark

RJ45_1/2

Two RJ45 LAN connector

CRT

DB15 VGA connector

PS2

PS/2 keyboard and mouse connector
