Brennenstuhl Smoke Alarm BR 5232 connect 230V - Manual (Page 16)

Technical Data
Device:
BR 5232
Test certificates: EN 14604
Protection class: IP 20
Reserve battery: 9 V DC carbon zinc (IEC
6F22)/ alkaline battery
(IEC 6LR61) or MN1604
In the event of a power
outage, the battery
takes over operation
for a least 1 year
Max. voltage: < 20 mA (Alarm)
Ambient temperature: 0°C – 40°C
Relative humidity: 10 %- 90 %
Sound level of signal: 85 dB (3 m distance)
Battery life: Min. 1 year
Networking: max. 12 smoke de-
tectors with a max.
cable length of 40 m
between each device
Selecting the mounting location
NOTICE: It is recommended that you install multi-
ple smoke detectors in your residence or building.
In order to provide minimal protection, it is
recommended that multi-floor buildings have one
smoke detector installed per floor.
16
Operating Instructions BR 5232
052109 Rauchmelder BR 5232 02.06.2009 19:19 Uhr Seite 16
