44
Fader function
• This function makes it possible to lower the volume of the front channels (FL, C and FR) or the rear channels (SL and SR) together. Use it for
example to adjust the balance of the sound from the different positions when playing multi-channel music sources.
1 Select “FADER”.
The channel switches in the order shown below each time
this button is pressed.
2 Press the button to reduce the volume of the front
channels, the button to reduce the volume of the rear
channels.
2
The channel whose channel level is adjusted lowest can be faded
to –12 dB using the fader function.
2
If the channel levels are adjusted separately after adjusting the
fader, the fader adjustment values are cleared, so adjust the fader
again.
This is only displayed when setting the fader control.
Dolby Surround Pro Logic mode
1 Select the Dolby Surround Pro Logic mode.
• The Dolby Pro Logic indicator lights.
(Main unit) (Remote control unit)
NOTE:
• There are four Dolby Surround Pro Logic modes (NORMAL,
PHANTOM, WIDE and 3CH. LOGIC). The AVR-5700 sets the
mode automatically according to the types of speakers set
during the system setup process (page 18).
2 Play a program source with the mark.
• For operating instructions, refer to the manuals of the
respective components.
Lit
2 The fader function does not affect the
SW, EL and ER channels.
FL 1 C 1 FR 1 SL 1 1 SR
SW 0 ER 0 EL 0 FADER 0
CH SELECT
ENTER
2
1
HOME THX CINEMA
TUNING
BAND TITLE MENU/GUIDE
MODE
MEMORY
USE/LEARN T.TONE MULTI DVD SET UP
RETURN
PANEL
DISPLAY
ON SCREEN
DOLBY / DTS SURROUND DIRECT
DSP SIMULATION 5CH STEREO STEREO
INPUT MODE ANALOG EXT.IN
MUTING
MASTER VOL.
AVR/AVC VIDEO DVD TV
AUDIO
VDP VCR
CD MD LOCK DECK
SYSTEM SETUP SURROUND PARAMETER
CH SELECT
SELECT
ENTER
HOME THX CINEMA DOLBY / DTS SURROUND DIRECT
DSP SIMULATION 5CH STEREO STEREO
INPUT MODE ANALOG EXT.IN
MASTER VOL.
VOLUME DISC SKIP+
1
1
DOLBY / DTS
SURROUND DOLBY / DTS
SURROUND
2
The EL and ER channels can only be adjusted when
“6CH/8CH EXTERNAL INPUT” is selected.
2 2
