Introduction
The Atlona 4K HDMI Multi-channel to Two Channel Balanced Audio Converter accepts up to Dolby
TrueHD and DTS-HD Master Audio then down converts it to two channel or one channel +4dBu
balanced audio. With built in RS-232, TCP/IP, and GUI control for audio mode switching, volume,
bass, and treble adjustment, the M2C-BAL provides an easy interface to control systems.
Package Contents
Features
• 1 x AT-UHD-M2C-BAL
• 1 x 5 pin female captive screw connector
• 1 x 3.5mm to DB9 adapter
• 1 x Locking 5V DC adapter
• 1 x User Manual
• Converts multi-channel audio into two/one channel audio
• Switch allows volume settings to be externally controlled (adjust) or force volume to factory
settings (default= 0 gain and flat EQ)
• RS-232, TCP/IP, and webGUI control options
• +4 dBu balanced analog audio output
• Compatible with all digital audio formats including lossless and lossy
• Audio EDID - Replaces the 2Channel audio portion of a display’s EDID with EDID that accepts all
PCM, LPCM, Dolby
® and DTS ® audio formats (including Dolby ® Digital, Dolby ® Digital Plus,
Dolby ® TrueHD, DTS Digital Surround™ and DTS-HD Master Audio™)
• LED audio status lights for all audio formats to determine incoming audio signals
• Up to 4K/UHD @ 30Hz pass through
• Control volume, bass, and treble using webGUI, TCP/IP, or RS-232
• HDCP management
