Commands

The command codes are case sensitive, do not change capitalization, spacing, or lettering.

Command

Feedback

Description

VersionX
ex. Version OSD

VersionX
ex. Version x.x.xx

Displays the software versions: ex. VersionMCU
firmware [MCU]
OSD menu [OSD]
DSP [DSP]
FPGA [FPGA]

Type

AT-UHD-M2C-BAL Displays the model information

Mreset

Reset device to manufacture default

HDCPSet1 X
Ex. HDCPSet1 on

HDCPSet1 X
ex. HDCPSet1 on

Set HDCP reporting mode of the HDMI input
X= on/off/sta

PrefTimg1 X

Set preferred timing X= 0-10

PrefTimg sta

PrefTimg1 X

Displays the currently selected preferred timing

SetMono1 X
Ex. SetMono1 on

Switch between stereo and mono analog audio output
X= on (mono), off (stereo), sta

VOUT1 +

VOUT1 XX

Increases volume output by 1

VOUT1 -

VOUT1 XX

Decreases volume output by 1

VOUT1 XX
Ex. VOUT1 -60

Set volume output to a specific value
XX= -80 to 6

VOUT1 sta

VOUT1 XX

Displays current volume output

VOUTMute1 X

Mute or unmute the output volume
X= on (mute), off (unmute), sta

BASS1 +

BASS1 XX

Increase bass level by 1

BASS1 -

BASS1 XX

Decrease bass level by 1

BASS1 XX
Ex. BASS1 -10

BASS1 XX
BASS1 -10

Set bass level to a specific value
XX= -15 to 15

TREBLE1 +

TREBLE1 XX

Increase treble level by 1

TREBLE1 -

TREBLE1 XX

Decrease treble level by 1

TREBLE1 XX
Ex. TREBLE1 -8

Set treble level to a specific value
XX= -15 to 15

AnalogOut X
Ex. AnalogOut bal

Set the analog audio to balanced or unbalanced output
X= bal (balanced), unbal (unbalanced), sta

SetHDMIPass X
Ex. SetHDMIPass on

SetHDMIPass X
Ex.

SetHDMIPass on

Set the HDMI port to output multichannel or 2Ch audio
X= on (multichannel), off (2Ch PCM), sta

UnBalLevel XX
Ex. UnBalLevel -20

Set the default unbalanced output audio level
XX= -80 to 6

[X] preferred timing -
0 Sink (pass through)

1 1280x800

2 1920x1080

3 1024x768

4 1280x720

5 1920x1200

6 1366x768

7 800x600

8 1600x900

9 2560x1440

10 3840x2160

Each command or feedback is terminated with a carriage return.

Note: If the command fails or is incorrect the feedback will be “Command FAILED”
