Technical AT-VGA-RS300S
Use
Input Ports
Output Ports
Sender
Stereo
350MHz
VESA
1 x VGA 1 x 3.5mm
1 x RS-232
1 x 3.5mm 1 x RJ45
1 x RJ45
.88lbs or 380g
.75lbs or 370g
1 x VGA
1 x 3.5mm
1 x RS-232
1 x 3.5mm
1 x VGA
Receiver
AT-VGA-RS300R
Video Bandwidth
Video Support
Audio Support
Input Video Signal
VGA Connector
RS-232 Connector
RJ45 Connector
3.5mm Connector
Mechanical
Housing
Dimensions
(LxWxH)
Weight
Model
Model
Package
Package
Mounting Type
Power Supply
Power Consumption
Operation Temperature
Storage Temperature
Relative Humidity
Equalization
Loop-out
ESD Protection
1.2 Volts (peak to peak)
RS-232 Signal Type Half-duplex
Human body model
Human body model ±15kV (air-gap discharge)
Human body model ±8kV (contact discharge)
Transmission 1920x1200 (WUXGA) up to 1000ft (330m) CAT5e
WE/SS 8P8C with 2 LED indicators
DE9 (9-pin D-sub female)
HD15 (15-pin D-sub female)
Jack for analog stereo audio or IR cable
Metal enclosure
(Sender/Receiver) 4.8x3.7x1(inch) or 123x95x25 (mm)
13x7.9x3.7(inch) or 330x200x95(mm)
Wall mount case with screws
Interlocked 5V 2A DC
6W
32°F - 104°F or 0°C - 40°C
-4°F - 140°F or -20°C - 60°C
20-90% RH (no condensation)
2.7lbs or 1240g
1 VGA local out + 1 audio local out on Sender
Continuous analog control
