Atlona AT HD 3GSDI - Manual (Page 4)

Technical
SDI standards
3G-SDI & HD-SDI & SDI
Auto 3G/HD/SD detection Yes
Video bandwidth 2.97Gpbs & 2.975/1.001Gbpss
Video support
[3G] 1080p50/59.94/60 (4:2:2)
[HD] – 720p@50/59.94/60Hz, 1035i@50/59.94/60Hz, 1080i@50/59.94/60Hz,
1080p@24/30Hz
[SD] – NTSC @59.94Hz, PAL @50Hz
Input signal [SD-SDI] SMPTE 259M
[HD-SDI] SMPTE 292M, 296M
[3G-SDI] SMPTE-424M
Output signal SDI
Output impedance 75Ω
Synchronization mode Internal synchronization or external synchronization
Eye pattern characteristics Extra low alignment jitter 0.05UI at HD
Cable equalization [3G-SDI] up to 90m (300ft)
[HD-SDI] up to 150m (500ft)
[SD-SDI] up to 300m (1000ft)
Audio support Yes
PCB stack-up 4-layer board [impedance control — differential 100Ω; single 50Ω]
Input 1x HDMI
Output 2x BNC [SDI]
BNC connector 75Ω inter-locked socket
HDMI connector Type A [19-pin female]
DIP switch 4-pin [video format / audio format / audio group / reserved]
Mechanical
Housing
Metal case
Dimensions
(L x W x H) Model 160 x 110 x 25mm [6.3”x4.3”x1”]
Package 270 x 175 x 80mm [10.6”x6.9”x3.2”]
Carton 450 x 370 x 300mm [1’5.7”x1’2.6”x11.8”]
Weight Model 420g [15oz]
Package 1030g [2.3 lbs]
Fixedness Inter-locked power supply
Power supply 5V 4A DC
Power consumption 3 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
SPECIFICATIONS
