The AT-HD-3GSDI provides a professional way to convert HDMI to 3G/HD/SD SDI in real time. The conversion
between SDI and HDMI is pure digital and guarantees no loss transformation for both audio and video. Plus,
with up to 8 channels audio support, 7.1 channel or 5.1 channel audio becomes available. The AT-HD-3GSDI
also provides 2 low jitter SDI outputs for daisy chain or multiple monitors. With the use of AT-HD-3GSDI, the
most popular uncompressed video interface in the consumer world is readily available for professional SDI
equipments!
• Supported high-definition (HD) formats:
NTSC [email protected], PAL 625@50, [email protected], 720p@24, 720p@25, [email protected], 720p@30, 720p@50,[email protected],
720p@60, 1080i@50, [email protected], 1080i@60, [email protected], 1080p@24, 1080p@25, [email protected], 1080p@30,
1080p@50, [email protected], 1080p@60
Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 270 Mbps
• Auto 3G/HD/SD-SDI detection
• HDMI 1.2 supported
• Two SDI compliant outputs
• External DIP Switch Configuration
INTRODUCTION
FEATURES
• 1x AT-HD-3GSDI
• 1x 5V power supply
• 1x user’s manual
PACKAGE CONTENT
