5.3. Top Panel
AT-HD-V14SS
1x4 HDMI Distribution Amplifier
with CAT5/6 Outs and 1 x Local HDMI Out
EDID
LEARNING
1080p 1080i
720p
Multi-CH Bitstream 2-CH
3D 2D
Default EDID
EDID LEARNING vs. Default EDID: When the DIP switch is set to Default EDID, users can adjust desired EDID
setting for the default EDID profile. When the DIP switch is set to EDID
LEARNING, the AT-HD-V14SS will learn the EDID from the device connected
to the HDMI
TM output port. Please see EDID LEARNING section for detail
information.
2D vs. 3D: Choose between 2D or 3D source content
2-CH vs. Multi-CH Bitstream: Choose between stereo audio or surround sound multi-channel audio source content
1080i / 720p vs. 1080p: Choose between HD 1080i / 720p or Full HD 1080p source content
