SPECIFICATIONS:
Model Name AT-HD-V14SS AT-HDRS AT-HD15SRS
Technical
Role of usage 1x4 Splitter / Sender Long range receiver Short range receiver
HDMI TM compliance HDMI TM 1.3c
HDCP compliance Yes
Video bandwidth Single-link 225MHz (6.75Gbps)
Video support 480i / 480p / 720p / 1080i / 1080p60 12-bit
Transmission
Full HD (1080p): 110ft (35m) [CAT5/6]
HD (720p/1080i): 200ft (60m) [CAT5/6]
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Equalization N/A 8-level digital None
Input TMDS signal 1.2 Volts (peak-to-peak)
Input DDC signal 5 Volts (peak-to-peak, TTL)
ESD protection
[1] Human body – ±19kV (air-gap discharge) & ±12kV (contact discharge)
[2] Core chipset – ±8kV
Input 1x HDMI TM 1x RJ45 1x RJ45
Output 1x HDMI TM + 4x RJ45 1x HDMI TM 1x HDMI TM
HDMI TM connector Type A (19-pin female) Type A (19-pin female) Type A (19-pin male)
RJ45 connector WE/SS 8P8C with 2 LED indicators
Mechanical
Housing Metal enclosure Metal enclosure Plastic molding
Dimensions
[L x W x H]
Model
4.3” x 7.6” x 1.1”
(110 x 194 x 27mm)
3.2” x 2.4” x 1”
(80 x 60 x 25mm)
1.8” x1” x 0.8”
(45 x 25 x 20mm)
Package
1’1” x 7.9” x 3.7”
(330 x 200 x 95mm)
10.6” x 6.9” x 3.2”
(270 x 175 x 80mm)
6.7” x 4.5” x 1.6”
(170 x 115 x 40mm)
Weight
Model 1.3 lbs (588g) 5oz (154g) 1oz (22g)
Package 2.2 lbs (985g) 1 lb (453g) 3oz (90g)
Fixedness Wall-mount with ears Wall-mount case Direct plug-in
Power supply 5V DC 5V DC None
Power consumption 10 Watts (max) 1 Watt (max) 0.5 Watt (max)
Operation temperature 32~104 °F (0~40°C)
Storage temperature -4~140 °F (-20~60°C)
Relative humidity 20~90% RH (no condensation)
