Deluxe 10” Radial Saw
SPECIFICATIONS
A workshop workhorse.
• Powerful 1 1 ⁄
2
HP capacitor start motor
develops up to 2 3 ⁄
4
HP.
• Built-in automatic blade brake stops
blade in seconds.
• Big 3 Ó depth of cut at 90° and 45°
miter: full 2 1 ⁄
4
Ó at 45° bevel.
•
Rips 24 Ó wide and crosscuts 12 3 ⁄
4
Ó .
•
Cast iron track and column support
assures strength and continued
accuracy.
•
Up-front controls, including blade
elevating crank, for greater operator
convenience.
•
Extra-large 24 3 ⁄
4
Ó x 42 Ó table provides
ample work support.
•
Built-in provisions for complete
adjustment and alignment of all
moving parts to maintain new saw
cutting accuracy for life of machine.
Model 33-990 Deluxe 10 Ó Radial Saw.
Includes basic machine with stand, 1 1 ⁄
2
HP,
single phase, 115/230V, 60 Hz., 3450 rpm
motor; automatic blade brake, 10
Ó saw blade
and blade wrenches.
Model 33-990
10
Ó Radial Saw
Ball bearing roller head for
smooth cutterhead travel and
effortless operation. Features a dual shaft (thread-
ed
5 ⁄ 8 Ó -12LH and 1 ⁄ 2 Ó -20RH)
for maximum utilization of
accessories.
Positive bevel and miter stops at commonly used angle positions.
Motor: ...................................................... 1 1 ⁄ 2 HP, 115/230V, 60 Hz.
Speed ............................................................................... 3450 rpm
Arbor ................................................................................
5 ⁄ 8
Ó -12 LH,
Rear shaft 1 Ъ
2
У - 20 RH
Blade:
Diameter .................................................................... 10
Ó (254 mm)
Arbor Hole .................................................................... 5 ⁄
8
Ó (16 mm)
Capacity:
Max. depth of cut .............................................. approx. 3
Ó (76 mm)
Max. depth of cut
at 45° bevel ................................................... approx. 2 1 ⁄ 4 Ó (57 mm)
Crosscut ................................................................. 12 3 ⁄ 4 Ó (324 mm)
Rip ............................................................................. 24 Ó (610 mm)
Dado Capacity ........................................................... 13 ⁄ 16 Ó (21 mm)
Bevel Positive Stops ................................................ 0°, 45° and 90°
Miter Positive Stops .................................................... 0°, 45° R & L
Table Size ......................................... 42
Ó x 24 3 ⁄ 4 Ó (1067 x 629 mm)
Overall Dimensions:
Width ....................................................................... 42
Ó (1067 mm)
Depth ......................................................................... 37 Ó (940 mm)
Height (on stand) ..................................................... 53 Ó (1346 mm)
Weight .................................................................... 178 Ibs. (81 kg)
For accessories, see page 29
®
