10 For accessories, see page 29
Sidekick ® 8 1 ⁄
4
” Builder’s Saw ®
SPECIFICATIONS
The Builder’s Saw that’s
got it all.
•
Cuts 2 1 ⁄
4
Ó at 90°; 1 5 ⁄
8
Ó at 45° blade
tilt—enough capacity to cut dimen-
sional 2 x 4 lumber.
•
Diecast aluminum table, with inte-
gral outfeed work support and T-slot
miter gage grooves, measures a full
26
Ó x 20 Ó .
•
Miter gage with adjustable positive
stops at 90° and 45° R&L for accu-
rate straight and angle cutting.
•
Self-aligning rip fence with single
control handle and easy-to-read
English/Metric rip scale.
•
Carbide-tipped 8 1 ⁄
4
Ó dia. x 18 ATB
saw blade included as standard
equipment.
•
Built-in holders and compartments
for miter gage, cord, rip fence,
blade guard, extra blade and
wrench set storage.
Model 36-275 Sidekick ® 8 1 ⁄ 4 Ó Builder’s
Saw ® . Includes basic machine with
15 amp., 120V, 60 Hz. motor; rip fence,
miter gage, see-through blade guard with
splitter and anti-kickback fingers, carbide-
tipped 8
1 ⁄ 4 Ó dia. x 18 ATB saw blade, table
insert, wrenches and instruction manual.
Model 36-275
Sidekick
® 8 1 ⁄
4
Ó Builder’s
Saw ®
Integral outfeed work sup-
port handles large panels and
long stock; slides in, out of the
way, when not in use. Built-in holders and compart-
ments for out-of-the-way miter
gage, rip fence, blade guard, extra
blade and wrench set storage;
easier accessibility when needed. Convenient carrying handle
and cord holder bracket for
safe and easy transport from
job to job. T-slot grooves hold miter
gage securely beyond front of
table, preventing it from falling
during wide cut-off operations.
Motor ..................................... 15 amp., 120V, single phase, 60 Hz.
Blade:
Diameter ................................................................... 8
1 ⁄ 4 Ó (210 mm)
Arbor ............................................................................. 5 ⁄
8
Ó (16 mm)
Speed ............................................................................... 4500 rpm
Capacity:
Maximum depth of cut at 90° ..................................... 2
1 ⁄ 4
Ó (57 mm)
Maximum depth of cut at 45° ..................................... 1 5 ⁄ 8 Ó (41 mm)
Maximum rip to right of blade .................................... 12 Ó (305 mm)
Table in front of blade at 1 Ó depth of cut ..................... 8 Ó (203 mm)
Maximum width of dado ............................................. 13 ⁄
16
Ó (21 mm)
Table:
Size ........................................................ 26
Ó x 20 Ó (660 x 508 mm)
with accessory extension wing ............ 32 Ó x 20 Ó (813 x 508 mm)
Height ..................................................................... 12 1 ⁄ 8 Ó (308 mm)
T-slot ............................................................ 3 ⁄
8
Ó x 3 ⁄
4
Ó (10 x 19 mm)
Overall Dimensions:
Height ..................................................................... 15
7 ⁄ 8 Ó (403 mm)
Width ......................................................................... 26 Ó (660 mm)
Depth ...................................................................... 25 3 ⁄ 8 Ó (645 mm)
Weight ................................................................... 48 1 ⁄
2
Ibs. (22 kg)
®
