13
DFI2309
If unit was operating prior to servicing allow at least 10 minutes for light bulbs and
heating element to cool off to avoid accidental burning of skin.
Disconnect power before attempting any maintenance or cleaning to reduce the risk of
electric shock or damage to persons.
TO REPLACE LIGHT HARNESS
1. Remove the trim and firebox from mantel.
2. Remove the trim from firebox.
3. Remove the (2) outer screws from the log grate.
4. Slide the light assembly out of the insert by pulling and lifting up on the log grate until
the light assembly comes out of the unit.
5. Cut the (2) light harness wires (blue, white) in between the flame motor cover and
the right light socket with wire cutters.
6. Strip the (2) light harness wire ends (blue, white) on the flame motor cover side.
7. Cut the (2) light harness wires (blue, white) in between the left and right light sockets
with wire cutters.
8. Remove the (2) light socket screws from the rear of the light assembly.
9. Remove light bulbs.
10. Remove light sockets by placing hand inside light assembly, grasping light socket
and pulling light socket until it snaps out of place.
11. Replace the (2) light sockets.
12. Wire connect the (4) light socket wires (blue to blue) (white to white) in between the
left and right light sockets with the supplied wire connectors.
13. Wire connect the (4) light harness wires (blue to blue) (white to white) in between the
flame motor cover and the right light socket with the supplied wire connectors.
