www.desatech.com 113680-01A 27
PARTS LIST
10,000 BTU/HR MANUAL CONTROL MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 25 of this manual.
PART NUMBER
KEY 10542 10543
NO. Manual NG Manual LP DESCRIPTION QTY.
1 114422-01 114422-01 Front Panel/Deflector Assy 1
2 ** ** Cabiet 1
3 113644-01 113644-01 Grill Guard 1
4 113588-01 113588-01 Baffle 1
5 114011-01 114011-01 Lower Baffle 1
6 113581-01 113581-01 Glass 1
7 113608-01 113608-01 Glass Bracket 1
8 104263-03 104263-03 Burner 1
9 098354-06 098354-06 Knob 1
10 097159-04 097159-04 Piezo Ignitor 1
11 098271-02 098271-09 Piezo Cable 1
12 099415-17 099415-18 Regulator 1
13 113706-01 113706-01 Inlet Tube 1
14 114263-01 114263-01 Outlet Tube 1
15 113678-01 113678-01 Pilot Tube 1
16 098508-01 098508-01 Valve Retainer Nut 1
17 104259-01 104259-02 Injector 1
18 099413-01 099413-02 Control Valve 1
19 099059-05 110803-02 ODS Pilot Assembly 1
19-1 098514-01 110186-01 Thermocouple 1
19-2 098594-01 098594-01 Ignitor Electrode 1
20 098200-04 098200-04 Valve Bracket 1
21 113586-01 113586-01 Right Burner Bracket 1
22 113587-01 113587-01 Left Burner Bracket 1
23 098249-01 098249-01 Pilot Nut 1
24 111421-01 111421-01 Snap Bushing 1
25 114013-01 114013-01 Baffle Cover Plate 1
26 113734-01 113734-01 Wall Mounting Bracket 1
27 099553-01 109121-01 Pilot Shield 1
28 NJF-8C NJF-8C Hex Nut 1
PARTS AVAILABLE — NOT SHOWN
113684-01 113684-01 Hardware Bag 1
105345-01 105345-01 Cable Tie 1
114351-01 114351-01 Lighting Instruction Tag (Eng) 1
114351-02 114351-02 Lighting Instruction Tag (Sp) 1
114351-03 114351-03 Warning Tag 1
** Not a field replaceable part.
