The following connection allows you to record TV programs.
Connecting with an Antenna
Video Connection
-11-
You may connect S-Video input to enjoy a clearer and brighter picture images. You can choose and
make the connection with any one of Video 1,2, or 3 inputs.
ANT/CABLE 1
Connection is not necessary in Mono mode.
Connect either S-Video or Video input to the unit. When both are connected, the output display will be
in S-Video.
Note
The stated connection does not comply with recording TV programs. You must make
the connection to the Antenna input socket as shown below for recording.
Connection Guide
1. Connect the antenna to the antenna input of the video
2. Make a connection of Antenna Output on Video and Antenna Input on TV with the coaxial cable
provided.
Operating Instructions
1. Adjust the channel selection switch at the rear side of the Video to 3 or 4.
2. Turn on the TV set, and adjust the channel to 3 or 4, to the number adjusted for step1.
3. Turn on the Video, insert the videocassette, and press the Play button.
Connecting with an External Source
