TOYOTA 2011 FJ Cruiser User Manual
Page 425
404
4-3. Do-it-yourself maintenance
Fuse
Ampere
Circuit
1
SPARE
10 A
Spare fuse
2
SPARE
15 A
Spare fuse
3
TOWING TAIL
15 A
Trailer lights
4
RR FOG
10 A
No circuit
5
OFFROAD LP
15 A
Offroad lamp
6
STOP
10 A
Stop lights, high mounted stop-
light, anti-lock brake system, trac-
tion control system, active traction
control system, vehicle stability
control system, AUTO LSD system,
multiport fuel injection system/
sequential multiport fuel injection
system, shift lock system
7
DEICER
20 A
No circuit
8
AUX LP
15 A
Driving lamp
9
TOWING BRK
30 A
No circuit
10
OBD
7.5 A
On-board diagnosis system
11
HEAD (LO RH)
10 A
Right-hand headlight (low beam)
*1
Right-hand headlight
*2
12
HEAD (LO LH)
10 A
Left-hand headlight (low beam)
*1
Left-hand headlight
*2
13
HEAD (HI RH)
10 A
Right-hand headlight (high beam)
*1
14
HEAD (HI LH)
10 A
Left-hand headlight (high beam)
*1
15
EFI NO.2
10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
16
INJ
10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
17
DRL
7.5 A
Daytime running light system
