PARTS LIST
Models TC36NE, VTC36NE, TC36PE, VTC36PE
PARTS LIST
BURNER ASSEMBLY FOR MODELS
TC36NE, VTC36NE, TC36PE AND VTC36PE
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 28 of this manual.
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
116341-01 Burner Pan Assembly
1
2
111311-01 Base Grate
1
3
116387-01 Bottom Firebox Base
1
4
26808
Valve Bracket
1
5
11107
Screw, #10-32 x 1/4 Zinc
4
6
111310-01 Firebox Bottom
1
7
11102
Screw, #8-32 x 3/8 Zinc
2
8
116344-01 Aluminum Tubing Assembly
1
9
111288-02 Flex Gas Line
1
10
108866-01 Elec. Pilot Assembly (Natural)
1
108866-02 Elec. Pilot Assembly (Propane/LP)
1
11
14569
Elec. Valve Assembly (Natural)
1
14570
Elec. Valve Assembly (Propane/LP)
1
12
11165
Screw #10 x 5/8 Zinc
1
13
111913-01 Burner Base Gasket
1
14
14500
Brass Fitting
2
15
116345-01 Pilot Bracket
1
16
26827
Switch Bracket
1
17
11226
Flat Washer, 7/8" ID x 2" OD
2
18
11214
Bulkhead Fitting with Washer
1
19
14296
Elbow, 3/8"
1
20
23102
Gas Orifice #40 Natural
1
23096
Gas Orifice #53 Propane/LP
1
21
11186
Screw, #8 x 32 x 1 Zinc
2
22
110058-01 Ignition Module
1
23
11147
Screw, 10-24 x 1/2 BLK
2
24
14129
Transformer, 24V Class 2
1
25
14115
Spade Tongue Connector
1
26
108863-01 24" Supply Connect Plug
1
27
14149
Spade 1/4 F RT. Angle
4
28
14126
16 GA Green Wire
1
29
14134
18 GA Black Wire
5
30
14120
Spade 1/4 Female Connector
4
31
17223
Magnet
2
32
23416
Electronic Components Board
1
33
11201
Nut, 8-32 Hex Zinc
4
