OWNER’S MANUAL
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 15 of this manual.
PART NUMBER FOR
CGP6L
CGP10L
KEY
NO.
DESCRIPTION
QTY.
1
098304-01
098304-01
Screw, #10 x 3/8"
2
2
099467-05
099467-05
Front Panel (Ivory)
1
3
099318-04
099318-04
Grill Guard
1
4
098342-01
098342-01
Grill Guard Clip
2
5
102018-01AA 102018-01AA Bottom Glass Retainer
1
6
098260-03
098260-03
Glass Panel
1
7
098532-03AA 098532-03AA Top Glass Retainer
1
8
M11084-38
M11084-38
Screw, #8 x 3/8"
8
9
098352-03BR 098352-03BR Deflector Unit
1
10
098271-03
098271-03
Ignitor Cable
1
11
098249-01
098249-01
Nut, M5
2
12
099059-03
099059-03
ODS/Pilot Assembly
1
12-1 098514-01
098514-01
Thermocouple
1
12-2 098594-01
098594-01
Ignitor Electrode
1
13
099386-02
099386-02
Burner
1
14
099387-05
099387-05
Pilot Tubing
1
15
098251-08
098251-07
Injector
1
16
099463-01
099463-01
Injector Holder
1
17
099415-02
099415-02
Pressure Regulator
1
18
099462-01
099462-01
Burner Tubing
1
19
099391-02
099391-02
Regulator Tubing
1
20
098276-01
098276-01
1/8" NPT Plug
1
21
099057-01
099057-01
Pressure Tap Fitting
1
22
099413-02
099413-02
Control Valve
1
23
099468-14
–
Cabinet Assembly (CGP6L Only)
1
–
099468-15
Cabinet Assembly (CGP10L Only)
1
24
102445-01
102445-01
Piezo Ignitor
1
25
099393-01
099393-01
Control Knob
1
26
098508-01
098508-01
Valve Retainer Nut
1
27
098303-02
098303-02
Screw, #6 x 5/16"
2
28
099553-01
099553-01
Pilot Shield
1
29
099818-01
099818-01
Internal Tooth Washer
1
PARTS AVAILABLE - NOT SHOWN
099395-10
099395-03
Control Position Label
1
100642-02
100642-02
Assembly, Hardware
1
