Page 17
17
104950
OWNER’S MANUAL
PARTS LIST
RJ70
∆
Not available as an assembly
**
Included in Rotor Kit (Part No. HA3004)
⊕
Included in Filter Kit (Part No. HA3014)
∞
Included in Pump Adjustment Kit (Part No. HA3020)
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
18-17
M8643**
Blade
4
18-18
FHPF3-5C
Screw, #10-32 x 5/8"
2
19
M50050
Rubber Cap
1
20
NTC-4C
Hex locknut
2
21
M50104-02
Bushing (wires)
1
22
M11084-26
Screw, #10-16 x 3/8"
6
23
098511-18
Lower Shell
1
24
M11271-8
Clip Nut
6
25
097061-01
Relay (motor start)
1
26
079010-18
Wire Assembly (red 16")
1
27
M10908-14
Screw, #8-32 x 3/8"
1
28
M29652-04
Rubber Airline
1
29
079973-01
Fuel Line
1
30
M16841-57
Wire Assembly (red 8
1
/
2
")
1
31
M10990-3
Rubber Bushing
1
32
M50876-05
Fuel Filter Assembly
1
(Includes bushing)
33
102482-01
Electronic Ignitor
1
34
M11084-29
Screw, #10-16 x 3/4"
2
35
099125-03
Terminal Board
1
36
099157-01
Rivet
1
37
097702-01
Fuel Tank Cap
1
38
097997-02
Flame-Out Control
1
39
098513-57
Fuel Tank
1
40
097194-02AA
Side Cover
1
41
M11084-26
Screw, #10-16 x 3/8"
4
42
099177-01
Hex Nut
1
43
097274-01
Jumper Plug
1
44
M9900-162
Wire Assembly (green 16")
1
45
M27417
Drain Plug
1
46
098226-01
ON/OFF Switch
1
47
097196-02
Switch Seal
1
PARTS AVAILABLE - NOT SHOWN
HA2210
Filler Neck Screen
1
102415-01
Wiring Decal
1
097204-22
Tradename Decal
1
097208-33
Nameplate Decal
1
M9900-170
Wire Assembly (Black 12")
2
KEY
PART
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
097190-01
Fuel Gauge
1
2
098511-36
Upper Shell
1
3
100647-01
Screw, #10-16 x 1/2"
6
4
098512-41
Combustion Chamber
1
5
097202-01
Receptacle
1
6
M16660
Photocell Bracket
1
7
M10908-2
Screw, #6-32 x 3/8"
2
8
HA3019
Photocell Assembly
1
9
102330-01
Power Cord
1
10
∆
Burner Head Assembly
1
10-1
100735-14
Nozzle
1
10-2
M10659-1
Nozzle Seal Washer
2
10-3
M10809-1
Nozzle Seal Spring
1
10-4
M8882
Nozzle Seal Sleeve
1
10-5
M51098-02
Burner Head Body
1
10-6
M50820-01
Barb Fitting
2
10-7
HA3012
Spark Plug
1
11
M11084-27
Screw, #10-16 x 1/2"
3
12
M30865-02
Bushing
2
13
099492-01
Strain Relief Bushing
1
14
097200-01
Fan
1
15
M50631
Rubber Bumper
2
16
M15823-39
Screw, #8-18 x 1/2"
2
17
101205-01
Motor and Relay Bracket
1
18
∆
Motor and Pump Assembly
1
18-1
102001-12
Motor
1
18-2
079975-02
Pump Body
1
18-3
M22009**
Insert
1
18-4
M22456-1**
Rotor
1
18-5
M29608
End Pump Cover
1
18-6
M29632
⊕
Lint Filter
1
18-7
M29633
⊕
Intake Filter
1
18-8
M29609
End Filter Cover
1
18-9
M12461-31
Screw, #10-32 x 1"
3
18-10 M8940
∞
Steel Ball (1/4" Dia.)
1
18-11 M10993-1
∞
Pressure Relief Spring
1
18-12 M27694
∞
Adjusting Screw
1
18-13 M22997
∞
Plug
1
18-14 M29612-01
⊕
Output Filter
1
18-15 M12461-31
Screw, #10-32 x 1"
6
18-16 M50016
Elbow, 90˚ (Barb Fitting)
1
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the correct
model and serial numbers (from the model plate), then the part number and description of the desired part.
