OWNER’S MANUAL
PARTS LIST
RJ45
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the correct
model and serial numbers (from the model plate), then the part number and description of the desired part.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 M51104-01 Handle 1
2 098511-36 Upper Shell 1
3 M11084-29 Screw, #10-16 x 3/4" 2
4 100647-01 Screw, #10-16 x 1/2" 6
5 098512-62 Combustion Chamber 1
6 M10908-2 Screw, #6-32 x 3/8" 2
7 103154-03 Photocell Bracket 1
8 M16656-23 Photocell Assembly 1
9 ∆ Burner Head Assembly 1
9-1 100735-22 Nozzle Assembly 1
9-2 102548-04 Ignitor Kit 1
9-3 104056-01 Nozzle Adapter 1
9-4 102336-01 Nozzle Adapter Bracket 1
9-5 104023-01 Screw/Washer Assembly 1
10 M11084-26 Screw, #10-16 x 3/8" 2
11 097033-01 Fan 1
12
∆
Motor and Pump Assembly 1
12-1 102001-22 Motor 1
12-2 079975-02 Pump Body 1
12-3 M22009** Insert 1
12-4 M22456-1** Rotor 1
12-5 M29608 Pump End Cover 1
12-6 M29632 ⊕ Lint Filter 1
12-7 M29633
⊕
Intake Filter 1
12-8 M29609 Filter End Cover 1
12-9 M12461-31 Screw, #10-32 x 1" 3
12-10 M27694
∞
Adjusting Screw 1
12-11 M10993-1
∞
Pressure Relief Spring 1
12-12 M22997
∞
Plug 1
12-13 M8940
∞
Steel Ball, 1/4" Diameter 1
12-14 M29612-01
⊕
Output Filter 1
12-15 M12461-31 Screw, #10-32 x 1" 6
12-16 103676-01 Nylon Elbow, 90
°
1
12-17 M8643** Blade 4
KEY PART
NO. NUMBER DESCRIPTION QTY.
∆
Not available as an assembly
** Included in Rotor Kit (Part No. HA3004)
⊕ Included in Filter Kit (Part No. HA3014)
∞ Included in Pump Adjustment Kit (Part No. HA3020)
12-18 FHPF3-5C Screw 2
13 M51105-01 Fan Guard 1
14 102330-01 Power Cord 1
15 099492-01 Strain Relief Bushing 1
16 NTC-4C Hex Lock Nut, 1/4-20 2
17 M11084-26 Screw, #10-16 x 3/8" 4
18 M50631 Rubber Bumper 2
19 097461-06AA Side Cover 1
20 101205-01 Motor Bracket 1
21 M30865-02 Bushing 1
22 M11271-8 Clip Nut 6
23 M50104-02 Bushing 1
24 M11084-26 Screw, #10-16 x 3/8" 6
25 M10908-14 Screw, #8-32 x 3/8" 1
26 098511-18 Lower Shell 1
27 M50814-06 Rubber Airline 1
28 079973-01 Fuel Line 1
29 M50876-02 Fuel Filter with bushing 1
30 M10990-3 Rubber Bushing 1
31 101695-01 Button Plug 1
32 102349-01 PCB Support 5
33 104068-02 Ignition Control Assembly 1
34 097702-01 Fuel Cap (Includes Gasket) 1
35 098513-100 Fuel Tank 1
36 M51108-01 Shell Heat-Shield 1
37 097190-05 Fuel Gauge 1
38 098226-01 On/Off Switch 1
39 097196-02 Switch Seal 1
40 097202-01 Receptacle 1
41 097274-01 Jumper Plug 1
42 097467-02 Button Plug 1
PARTS AVAILABLE - NOT SHOWN
104949-01 General Information Decal 1
103814-01 Wire Tie 1
