Page 15
13
Operation - TV
P
P
P
i
i
i
c
c
c
t
t
t
u
u
u
r
r
r
e
e
e
-
-
-
I
I
I
n
n
n
-
-
-
P
P
P
i
i
i
c
c
c
t
t
t
u
u
u
r
r
r
e
e
e
PIP function:
The PIP function allows you to watch two screens on the display from two different
sources at the same time. For example; you can watch a TV channel and a component
video source at the same time. See PIP structure chart below.
Press:
PIP
To start the PIP function.
Off->PIP(Small) ->PIP(Medium) ->PIP(Large)-> PBP -> POP
SOURCE
To select the sub screen’s source. (See the PIP structure below)
POSITION To adjust the PIP position.
SWAP
To switch the picture of main screen to sub screen.
Freeze
To freeze the PIP main screen.
[Basic function]
You can control PIP function easily by remote control.
PIP mode PIP source PIP position Swap PIP PBP
source & swap
POP PIP size –small PIP size–medium PIP size–large Freeze the PIP
Source & swap main screen
Note: 1. M: main screen; S: sub-screen
2. The PIP submenu can be used to control the sub-screen size.
3. The “SOURCE” button selects the sub-screen. Use the “SWAP” or “FREEZE” buttons
to manipulate the main screen.
PIP structure
Main Screen
PIP
TV
AV1
AV2
AV3
S-Video
Component1
(Y1Cb1Cr1)
Component2
(Y2Pb2Pr2)
VGA
DVI
TV
y
y
y
AV1
y
y
y
AV2
y
y
y
AV3
y
y
y
S-Video
y
y
y
Component1
(Y1Cb1Cr1)
y
y
Component2
(Y2Pb2Pr2)
y
y
y
y
y
y
VGA
y
y
y
y
y
y
y
Sub-
Screen
DVI
y
y
y
y
y
y
y
y
