11
Operation - TV
T T T V V V / / / P P P C C C P P P a a a r r r a a a m m m e e e t t t e e e r r r s s s
TV Parameters
Press “MENU” and make sure the “TV Parameters” is shown on the screen.
Adjusting the TV setting:
y Brightness: Alters the brightness of the image.
y Contrast: Alters the ratio of light to darkness.
y Sharpness: Adjusts the sharpness of the color.
y Saturation: Alters the color saturation.
y Hue: Alters the color intensity.
y Color temp: Adjusts the color temperature of the
picture. Three options are available here: 6500, 7500,
9300, and USERS.
y Format: Two options are available here: Full screen
(16:9) and 4:3.
16:9 4:3
PC parameters
Adjusting the picture setting:
y
Brightness: Alters the brightness of the image.
y Contrast: Alters the variation between light and
darkness.
y Auto: Auto adjusts the position of the image.
y Auto color: Auto adjusts the color balance.
Note: “AUTO COLOR” function is only available in
“VGA” and “Component 2” input sources. By accessing
“ALL RESET” function in “General Settings”, the color
will return to the factory default setting.
y Clock: Adjusts the clock frequency.
y Phase: Adjusts the phase frequency.
y H-Position & V-Position: Adjusts the horizontal and
the vertical position of the image.
y Color Temp.: Adjusts the color temperature of the
picture.
y Format: Two options are available here: Full screen
(16:9) and 4:3.
y
Color Temp.
Set Image:
