6 7
Cleaning and Maintenance
Maintenance
Light bulb Replacement
light bulb replacement is considered to be a homeowner
maintenance operation. If all of the lights do not work,
before replacing any bulbs, check to make sure power is on
at the circuit breaker or fuse box.
Replace the light bulbs only with dacor Part No. 700975.
Halogen Bulb Replacement Kit consist of a single bulb and
suction cup, available from any authorized dacor parts
dealer.
To replace the light bulb:
Remove the right filter and turn off the main power 1.
switch.
gently push the suction cup on the light replacement 2.
tool a (provided with you range hood) onto the lens of
the light bulb B .
turn the tool counter-clockwise until the bulb comes 3.
loose.
Remove the tool from the bulb and put it on the lens of 4.
the replacement bulb.
WARNING
to prevent electric shock turn off power at the fuse or
•
junction box before replacing the light bulb.
to avoid personal injury, make sure the cooktop or
•
range, the hood and the light are cool before changing
the light bulb.
Screw the new bulb into the light fixture clockwise until 5.
it is tight. turn on power at the fuse or junction box.
turn on the main power switch and touch the light key
to make sure it is working.
Replace the filter. 6.
Replacement Parts
DACOR PART # DESCRIPTION
700975 Halogen Bulb Replacement Kit
101617 Filter
Product Specifications*
total Connect load 120 vac, 60 Hz, 9 amps MaX
(10 amp MaX surge)
Filters Mesh type, dishwasher safe
lights 120 vac, 60 Hz, 75 W
*Specifications subject to change without notice
b
A
3
1
2
