28
Using program guides
To turn off the Picture-In-Guide feature :
1. Press the remote control GUIDE button.
2. Press the GUIDE button again to access the Options menu tab.
Press the remote control GUIDE
button while the program guide
appears on-screen to display the
Guide Options menu.
3. Highlight the Picture-in-Guide menu button.
4. Press SELECT to toggle the feature off.
Logo guide
• Select your favorite channels, rather than selecting specific programs.
• The current program title appears above the logo grid as you highlight each
channel. Only current programming is available in the Logo Guide.
• Video of the current program appears in the Picture-in-Guide window as
you highlight each channel.
Use the Channel (CH) button to scroll through the guide entries a full page at a
time, or use the joystick to scroll through the guide entries one at a time.
You can display the most channels per screen as shown on page 29 by turning
off the Picture-in-Guide feature, using the description-only mode.
PROGRAM GUIDE
All Channels
Thu, Feb 7 6:00PM
The Weather Channel
CC
None 6:00PM - 7:00PM Weather. Local and national
forecast, weekly planner and weekend outlook;
severe weather focus at 10 minutes to the hour.
Series, Interactive.
The Weather Channel
DIRECTV INTERACTIVE Center
Today 6 PM 6:30 7 PM 7:30
DIRECTV Customer News
The Weather Channel
Local Channel Ordering Information
ALL DAY
TM
R
R
DIRECTV Pay Per View Previews
DIRECTV FREEVIEW R R
R
®
Logo guide with Picture-In-Guide active
A description of the program currently
airing on the highlighted network
menu appears here, if available.
Thu, Feb 7 6:00PM
CC
Picture-in-Guide
An image of the currently
airing program highlighted
in the menu selection
appears here
LOGO GUIDE
All Channels
Title of the program on the network selected in menu
