3 FORM NO. L-21208-C-0908
Register Name Type Page Register Name Type Page
Product Information Setup
1-4 Product Name Read Only 4 63 Torque Actuator Read/Write 8
6-7 Product Number Read Only 4 64 Torque Actuator Inertia Read/Write 8
8-9 Serial Number Read Only 4 65 Tension Zone Selection Read/Write 8
10-11 Software Part Number Read Only 4 66 Minimum Output Read/Write 8
12 Software Revision Read Only 4 67 Maximum Output Read/Write 8
Modbus Comm Setup 68 Standby Output Read/Write 8
15 Baud Rate Read/Write 5 69 Web Material Selection Read/Write 8
16 Modbus Device Address Read/Write 5 70 Average Web Width Read/Write 9
17 Parity Read/Write 5 71 Maximum Roll Diameter Read/Write 9
18 Stop Bits Read/Write 5 72 Minimum Core Roll Diameter Read/Write 9
19 Remote Communications Reset Write Only 5 Display
Diagnostics 78 Display Units Read/Write 9
30 Alarm Status Read Only 5 79 Language Read/Write 9
31-32 Load Cell 1 Tension Read Only 5 Control
33-34 Load Cell 2 Tension Read Only 5 80 Panel Write Enable Read/Write 9
35 Control Output Read Only 6 81 Manual/Automatic Mode Read/Write 9
36-37 Roll Diameter Read Only 6 82 Manual Output Level Read/Write 9
38 Run/Stop Read/Write 6 83 Alarm Acknowledge Write Only 10
39 Splice A Read/Write 6 84 Output On/Off Read/Write 10
40 Splice B Read/Write 6 Signal Selection
41 Adaptation Read Only 6 85 Run/Stop Signal Read/Write 10
43-44 Taper Tension Setpoint Read Only 6 Diameter Sensor Calibration
Tuning 87 Diameter Sensor Installed Write Only 10
45 Taper Tension Enable Read/Write 6 88 Diameter-Core Size Read/Write 10
46-47 Tension Setpoint Read/Write 7 89 Diameter-Large Roll Size Read/Write 10
48 Taper Read/Write 7 90 Diameter Measure Flag Read/Write 11
49-50 Taper Delay Read/Write 7 Tension Calibration
51 Gain Read/Write 7 73-74 Minimum Tension Setpoint Read/Write 11
52 Stabilization Read/Write 7 75-76 Maximum Tension Setpoint Read/Write 11
53 Initial Adaptation Read/Write 7 77 Tension Calibration Set Read/Write 11
54 Splice Adaptation Read/Write 7 93 Load Cell Measure Flag Read/Write 12
55 Adaptation Rate Read/Write 7 94-95 Tare Tension-Calibration Set 1 Read/Write 12
56 Remote Tension Setpoint Enable Read/Write 7 96-97 Span Tension-Calibration Set 1 Read/Write 12
Setup 98-99 Tare Tension-Calibration Set 2 Read/Write 12
60 Tension Monitor Enable Read/Write 8 100-101 Span Tension-Calibration Set 2 Read/Write 12
61 Tension Alarm Tolerance Read/Write 8 102-103 Tare Tension-Calibration Set 3 Read/Write 13
62 Alarm Output Type Read/Write 8 104-105 Span Tension-Calibration Set 3 Read/Write 13
RSTC1000 MODBUS TABLE OF REGISTERS
