Mounting dimensions, Figure 13 mb05, Continued...) – Nexen MB25B 911996 User Manual
Page 9
FORM NO. L-20127-L-0513
9
2.36
[60]
1.87
[47.5]
1.00
[25.5]
.69
[17.5]
2.09
[53]
2.72
[69]
1.59
[40.5]
Wall Mounting
Bracket
.39
[10]
2.95
[75]
1.00
[25.5]
2.36
[60]
1.73
[44]
.69
[17.5]
.59
[15]
3.62
[92]
Pivot Point
3.31
[84]
1.26
[32]
.30
[7.5]
.20
[5]
4-M5 X 9
From Bottom
1.26
[32]
4-Drill 4.5
Spot Facing
9 Dia. X 5.5
.75
[19]
16.4’ [5M]
Cable
.16
[4]
.08
[2]
.08
[2]
.47
[12]
Roll Center
Position
4 - 7 Dia. Mounting
Holes
.24
[6]
4-M5 X 9
.71
[18]
.98
[25]
4-M5 X 14
3.74
[95]
FIGURE 13
MB05
2.24
[57]
.87
[22]
1.77
[45]
2.32
[59]
3.15
[80]
1.51
[38.25]
in
[mm]
MOUNTING DIMENSIONS
(continued...)
