1

FORM NO. L-20014-L-0210

GENERAL SPECIFICATIONS

Specifications
Torque

Up to 424 Nm (3750 in-lbs)

Actuation Pressure

1 - 5.5 bar (14.5 - 80 psi)

Service Temperature 4.5º - 104º C (40º - 220º F)
Approximate Weight Brake: Up to 13.2 kg (29 lbs)

Drum: Up to 14.5 kg (32 lbs)

GENERAL SAFETY PRECAUTIONS

CAUTION

Watch for sharp features when
interacting with this product. The parts
have complex shapes and machined
edges.

WARNING

Ensure proper guarding of the product is
used. Nexen recommends the machine
builder design guarding in compliance
with OSHA 29 CFR 1910 “Occupa-
tional Safety and Health Hazards.”

WARNING

This product is capable of emitting a
spark if misused, therefore is not
recommended for use in any explosive
environment.

CAUTION

Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.

CAUTION

This product has possible pinch points.
Care should be taken when interacting
with this product.

CAUTION

This product has possible pinch points.
Care should be taken when interacting
with this product.

CAUTION

Surface temperature may exceed safe
handling limits during operation. Do not
touch.
