Ryobi RY34421 - Manual (Page 3)

3
RYOBI 30
cc
STRING TRIMMERS
MODEL NUMBERS — RY34421, RY34441
FIGURE A PARTS LIST
Key Part
No. Number Description Qty.
23 570400001 O-Ring ......................................................... 1
24 308842007 Throttle Cable .............................................. 1
25 940680023 Hot Surface Label ........................................ 1
26 940734067 Starting Label .............................................. 1
27 120950028 Upper Boom Assembly (Incl. Key No. 28) ... 1
28 940657034 Warning Label.............................................. 1
29 940705020 Logo Label ................................................... 1
30 940991026 C430 Label (RY34421) ................................. 1
940991027 S430 Label (RY34441) ................................. 1
31 T660619001 Screw (#6-19 x 1/2 in.) ................................ 2
32 518548001 CE Cover (Bottom Cover) ............................ 1
33 308431002 Lead Assembly (Inc. Key No. 5) .................. 1
34 940654088 Combustion Warning Label ......................... 1
35 940216002 Choke Label ................................................ 1
36 940971028 Oil Hang Tag ................................................ 1
37 678818001 Spring .......................................................... 1
38 690140011 Compression Spring .................................... 1
39 660345001 Screw (M4 x 12 mm).................................... 1
40 521608001 Choke Plate ................................................. 1
41 308398004 Air Filter Base .............................................. 1
42 521609001 Choke Lever ................................................ 1
Not Shown:
987000857 Operator’s Manual ....................................... 1
Key Part
No. Number Description Qty.
1 660563002 Screw (M4 x 20 mm).................................... 4
2 120950026 Control Handle Assembly ............................ 1
3 518695002 Trigger Lock ................................................. 1
4 638431001 Strap Hanger ............................................... 1
5 760700002 Switch (Momentary Contact) ....................... 1
6 570234002 Rear Handle ................................................. 1
7 678029002 Hex Nut (M6.3 x 1) ....................................... 1
8 310816002 Fuel Cap Assembly ..................................... 1
9 521403001 Air Box Cover .............................................. 1
10 310302001 Oil Cap/Dipstick (Incl. Key No. 23) .............. 1
11 870301002 Spark Plug (Champion RY4C) ..................... 1
12 660634001 Screw (#8-16 x 5/16 in.) .............................. 1
13 660697002 Bolt (M6 x 1 x 20 mm) ................................. 1
14 660510005 Screw (M5 x 11 mm).................................... 1
15 308991001 Front Handle Assembly
(Incl. Key No. 16-19) .................................... 1
16 518738001 Front Handle ................................................ 1
17 660643008 Bolt (1/4-20 x 40 mm) .................................. 1
18 678008001 Washer (1/4 in.) ............................................ 1
19 518949001 Wing Nut (1/4-20) ........................................ 1
20 310536001 Top Cover Assembly ................................... 1
21 518696002 Throttle Trigger ............................................ 1
22 690694002 Throttle Trigger Spring ................................. 1
