2

USER’S GUIDE 2609/2639

AUTO

With this setting, the watch automatically selects either the

Otakadoya Mountain signal (40kHz) or the Hagane Mountain

signal (60kHz), whichever is strongest.

* The frequency first used by the watch is the one that was

last successful.

40

With this setting, the watch always receives the Otakadoya

Mountain signal (40kHz).

60

With this setting, the watch always receives the Hagane

Mountain signal (60kHz).

Turning Auto Reception On and Off

1.

Display the setting screen.

Hold down the A

A

A

A

A button

for two seconds.

2.

Display the transmitter selection mode setting screen.

Press the CCCCC button three

times.

3.

Turn auto reception on or off.

Press the D

D

D

D

D button to

toggle auto reception ON

and OFF.

4.

Exit the setting screen.

Press the A

A

A

A

A button twice.

This exits the setting screen and returns to the normal

timekeeping screen.

The display also will return to the normal timekeeping screen

automatically if you do not perform any operation for about

two or three minutes.

Viewing the Last Reception Date and Time

In the Timekeeping Mode:

Press the D

D

D

D

D button.

This displays the date and time

that signal reception was

complete and the current time

and date were adjusted.

To return to the timekeeping

screen, press the D button

again.

The display also returns to the

normal timekeeping screen

automatically if you do not

perform any operation for about

one or two minutes.

Important!

The calibration signals received by this watch include two data

groups: an hour-minute-second group and a year-month-day group.

Both the hour-minute-second

group and year-month-day group

were not received. It will not

remain on the display if only the

hour-minute-second group is

received.

Specifying the Transmitter

Selection Mode in Japan

When Tokyo (TYO) is selected as the Home City, you can select

either of two different transmitters for reception.

1.

Display the setting screen.

Hold down the A

A

A

A

A button

for two seconds.

2.

Select the transmitter selection mode you want.

Press the D

D

D

D

D button.

3.

Exit the setting screen.

Press the A

A

A

A

A button twice.

This exits the setting screen and returns to the normal

timekeeping screen.

The display also will return to the normal timekeeping screen

automatically if you do not perform any operation for about

two or three minutes.

Time setting is incorrect following signal reception.
Possible Cause:

Summer time is turned on or the wrong

Home City is selected.

Corrective Measures:

Turn off summer time so the DST

indicator is not on the display.

Configure the watch for the correct DST

setting and Home City setting.

If you cannot receive the calibration signal or if the current time

setting is incorrect after signal reception, check the current setup

of the watch. The following are the watch's factory default

settings, which are configured automatically whenever you have

the battery of the watch replaced.

Auto Receipt

Transmitter

Home City

Summer Time

On
Auto Japan transmitter select

(40kHz/ 60kHz)

Tokyo

Auto switching in accordance

with signal data

Troubleshooting

Cannot perform manual reception.
Possible Cause:

The watch is not in the Timekeeping Mode

or World Time Mode.

The Home City is set to a city other than

TYO

(Tokyo), NYC (New York), CHI

(Chicago), DEN (Denver), or LAX (Los

Angeles).

Corrective Measures:

Perform manual reception while a time

screen is on the display in the Timekeeping

Mode or World Time Mode only.

Change Home City To TYO (Tokyo), NYC

(New York), CHI (Chicago), DEN

(Denver), or LAX (Los Angeles).

The

icon is not displayed even though auto reception is

turned on.
Possible Cause:

A single receive operation was not

successful.

Both the hour-minute-second group and

year-month-day group were not received.

The watch is not in the Timekeeping Mode

or World Time Mode when an auto

reception time is reached.

You performed manual reception, which

clears the icon from the display.

Corrective Measures:

Check to make sure the watch is in a

location where it can receive the signal.

Place the watch in a location where

reception conditions are good.

Make sure that the watch is in the

Timekeeping Mode or World Time Mode

during the auto reception times.

The icon disappears from the display

whenever you change the current time

setting manually.

Calibration Signal Reception

Precautions

Auto reception can be performed while the watch is in the

Timekeeping Mode or World Time Mode only.

Operating any button while auto reception is in progress will

cause the watch to beep and then exit the receive operation.

Make sure you are within the range of the calibration signal

transmitter before performing the receive operation. Remember

that geographic contours, nearby buildings, the season, and the

time of day can make reception impossible even when you are

within range of the transmitter.

Proper reception may be impossible if there is something blocking

the signal. If reception is unsuccessful, try again.

This watch is designed to adjust its current time setting in

accordance with the calibration signals transmitted in Japan and

the United States only. Note that you will need to make your own

adjustments when using this watch outside of Japan or the United

States, or in any area that is outside the range of one of the

receivable time calibration signal transmitters.

When the watch is unable to adjust its time signal using the

calibration signal for some reason, timekeeping accuracy is within

±

15 seconds per month.

Strong electrostatic charge can cause timekeeping error.

Signal reception is cancelled if an alarm starts to sound while it is

being performed.

The watch's calendar shows dates up to the year 2099.

Attempting a receive operation after that causes an error.

If only the hour-minute-second group is received, the Timekeeping

Mode date at the time of reception is recorded as the last

reception date.

displayed
not displayed

Hour-minute-second group and year-

month-day group received
Hour-minute-second group only received

Not displayed

The following explanation covers the radio-controlled timekeeping function only.

For other functions, go to the download page for Module 2608 or 2638,

which are the export models that have the same functions, except for radio-controlled timekeeping.
