Nintendo 3DS - Manual (Page 52)

100 101
Consumer Inf
orma
tion
Consumer Inf
orma
tion
Specific
ations
Specific
ations
Specifications
Nintendo 3DS system
Nintendo 3DS battery pack
Nintendo 3DS charging cradle
Nintendo 3DS AC adapter
Model name: CTR-007
Input/output: DC 4.6V 900mA
Dimensions: Height: 86.5 mm / width: 138.2 mm / thickness: 31.8 mm
Weight: Approximately 87.4 g
Model name: WAP-002 (USA)
Input: 120V 60Hz 7W
Output: DC 4.6V 900mA
Dimensions: Height: 67.5 mm / width: 47.7 mm / thickness:23.0 mm
Weight: Approximately 80 g
Cord length: Approximately 1.9 m
Compatible products: Nintendo 3DS, Nintendo DSi XL, Nintendo DSi
Model name: CTR-003
Battery type: Lithium-Ion
Power capacity: 5Wh
Model name: CTR-001 (USA)
LCD screens Upper Screen: Widescreen LCD display, enabling 3D view without the need for
(Screen size/pixel count) special glasses. Capable of displaying approximately 16.77 million colors. 3.53-inch
display (76.80 mm horizontal x 46.08 mm vertical) with 800x240 pixel resolution
(400 pixels are allocated for each eye to enable 3D viewing).
Lower Screen: LCD Touch Screen. Capable of displaying approximately 16.77 million
colors. 3.02-inch display (61.44 mm horizontal x 46.08 mm vertical) with 320x240
pixel resolution.
Power source AC adapter (WAP-002 (USA), Battery pack (CTR-003)
Wireless frequency: 2.4GHz band
Wireless standards: IEEE802.11b/g
Recommended wireless distance: Within 98’ (30 m). Depending on surrounding conditions, this
distance may be less.
Camera functions: Lens: Single focus. Capture element: CMOS. Active pixel count: Approx. 300,000
pixels.
Clock features: Maximum daily variance: ± 4 seconds
Speakers: Stereo (with pseudo-surround support)
Input/output: Game Card slot, SD Card slot, AC adapter connector, charging cradle terminal, and
stereo headphone output jack
Sensors: Motion sensor, gyro sensor
Maximum power consumption: Approximately 4.1W (while charging)
Operating environment: Temperature, 41˚F – 95˚F (5˚C – 35˚C) / humidity, 20-80 percent
Dimensions: Height: 74 mm / width: 134 mm / thickness: 21 mm (when closed)
Weight: Approximately 235 g (including battery pack (CTR-003), stylus (CTR-004), and SD
Card)
Charge time: Approx. 3 hours and 30 minutes
Battery endurance: Please see page 21.
