Fluke 77 - Manual (Page 18)

2-1
Chapter 2
Theory of Operation
Contents Page
2-1. Introduction.................................................................. 2-3
2-2. Functional Block Description ...................................... 2-3
2-3. Detailed Description .................................................... 2-3
2-4. Voltage Signal Conditioning ................................... 2-3
2-5. Current Conditioning............................................... 2-4
2-6. Ohms........................................................................ 2-4
2-7. Additional Circuitry................................................. 2-4
2-8. AC Converter ...................................................... 2-4
2-9. Active Filter ........................................................ 2-5
2-10. Rotary Switch...................................................... 2-5
2-11. A/D Conversion................................................... 2-5
