Web Programming
90
XBLUE Networks
6
SI
P
SIP Proxy Server
•
Server mode: - The X2020 can be set to two different server types, Normal - used when you are not
connecting to the X-50 system or X-50 when you are connected to a X-50 system.
•
SIP Proxy Server - Enter the LAN or WAN IP address of the SIP Proxy Server.
•
Outbound Proxy Server: - Enter the LAN or WAN IP address of the SIP Proxy Server.
•
Server Port: - Enter the port number that will be used when connecting to the SIP proxy Server. If con-
necting to an X-50 use port 5070.
•
SIP Secondary Proxy Server: - Enter a different LAN or WAN IP address, from the Primary SIP Server, to
connect to in the even that the primary SIP Proxy Server is offline.
•
SIP Surviving Proxy Server: - Enter a different LAN or WAN IP address, from the Primary and Secondary
SIP Server, to connect to in the even that both the primary and Secondary SIP Proxy Server is offline.
SIP Registrar Server
•
Registrar Server: - Enter the LAN or WAN IP address of the Registrar Server. The Default, when con-
necting to the LAN is 192.168.10.1
•
Registrar Outbound Server: - Enter the LAN or WAN IP address of the Outbound Server. The Default,
when connecting to the LAN is 192.168.10.1
•
Registrar Server Port: - Enter the port number that will be used when connecting to the SIP proxy
Server. If connecting to an X-50 use port 5070.
•
Registrar Expire Time (sec): - Enter the Expire Time for the Registrar SIP Server
Subscriber Information
•
Phone Number: - Enter the extension number (up to four digits) that will be used when calling your
extension.
•
Display Name: - Enter the Name (up to thirty characters) that will appear in the display when you are
calling other extensions.
•
Authorized ID: - Enter the name or number (up to four characters) that will be used to authenticate
your extension with the SIP Proxy Server.
•
Authorized Password: - Enter the password (up to eighteen characters) that will be used to authenticate
your extension with the SIP Proxy Server.
•
End Dial on #: - Check this feature if you would like to end every dial string with the # Key.
•
DTMF Type: - There are three settings for DTMF type; RFC2833, which is used in the United States,
Tone (InBand) and SIP-Info, which are used in other locations.
•
RFC2833 Payload: - The payload is the amount of information that one packet will contain. Change this
setting may cause erratic operation.
Session Timer
This timer is mostly used with remote or WAN telephones. Each time this timer expires, the remote telephone will
send the X-50 gateway notification that it is still up and operational; this is commonly called a “Keep Alive Signal”.
Generally, telephones installed on the LAN, especially with static IP addresses, will not have to use this timer.
•
Enable Session Timer: Click on the Check Box to enable the Session Timer. This timer is usually used
with WAN phones but not LAN phones.
