Specifications
All specifications are subject to change at any time, in order to improve the
product.
■
Signal to Noise ratio (main outputs)
:
–90 dB (ref 1V rms, A-wtd.)
■
Input impedance
:
25 kΩ (balanced)
■
Output impedance
:
50 Ω
■
Voltage gain range, without EQ
:
-15 to +5 dB dB
■
Maximum input level, at maximum level & boost
:
1V rms
■
Power consumption:
33W
■
Thermal load:
112 BTU
■
Mains voltage
:
115V or 230V
■
Overall dimensions
:
4” H x 17” W x 14
7
⁄
8
” D
10.2cm H x 43.2cm W x 37.8cm D
■
Shipping weight
:
34 lbs. (15.4 kg)
For more information, see your Wisdom Audio dealer, or contact:
Wisdom Audio
1572 College Parkway, Suite 164
Carson City, NV 89706
www.wisdomaudio.com
[email protected]
Ph: 775.887.8850
Fax: 775.887.8820
