Page 11: Versatec base series installation manual
11
VERSATEC BASE SERIES INSTALLATION MANUAL
Hanger Bracket Locations
B
C
A
E
D
G
F
Left
D
E
F
G
Right
Vibration Isolator
W asher
Hex Nuts
(not supplied)
Bolt and
Lockwasher
3/8”
Threaded Rod
(not supplied)
Compressor
Section
Compressor
Section
Air Handler
Section
Air Handler
Section
Hanger Dimensions
Model
Hanger Kit
Part Number
Unit Hanger Dimensions
A
B
C
006-012
in.
99S500A04
35.8
21.8
18.1
cm.
90.9
55.4
46.0
015-018
in.
99S500A04
35.8
25.1
21.4
cm.
90.9
63.8
54.4
024-030
in.
99S500A04
42.8
25.1
21.4
cm.
108.6
63.8
54.4
036
in.
99S500A04
42.8
25.1
21.4
cm.
108.7
63.8
54.4
042-048
in.
99S500A04
45.8
25.1
21.4
cm.
116.3
63.8
54.4
060
in.
99S500A04
48.8
28.1
24.4
cm.
124.0
71.4
62.0
070
in.
99S500A04
53.8
28.1
24.4
cm.
136.7
71.4
62.0
09/26/12
Weight Distribution
Model
Vertical
Shipping
Weight
Horizontal
Shipping
Weight
Horizontal Weight Distribution
Front
Back
D
E
F
G
006-
012
lb.
111
112
44
21
19
28
kg
50
51
20
10
9
12
015-
018
lb.
171
176
67
32
32
45
kg
78
80
30
15
15
20
024
lb.
245
242
85
47
45
65
kg
111
110
39
21
20
29
030
lb.
245
242
85
47
45
65
kg
111
110
39
21
20
29
036
lb.
267
265
95
60
50
60
kg
121
120
43
27
23
27
042
lb.
305
310
105
68
60
77
kg
138
141
48
31
27
35
048
lb.
305
310
105
68
60
77
kg
138
141
48
31
27
35
060
lb.
344
350
115
77
68
90
kg
156
159
52
35
31
41
070
lb.
357
378
130
80
73
95
kg
162
171
59
36
33
43
10/03/12
