PARTS LISTS
FUEL PUMP VOLTAGE BOOSTER UPGRADE
5A102-030 - FPB ASSY, NON-PRG, UNIV.
PART NO.
DESCRIPTION
QTY
007128
INSTR, UNIV. FPVB UPGRADE
1
008601
BOX, CARDBOARD, PUMP BOOSTR
1
008602
INSERT, CARDBOARD, PUMP BOOSTR
1
5A002-030
VOLT BOOSTER, STD VORT
1
5W001-009
16-14GA MALE SLIDE INSULATED
2
5W001-010
16-14GA FEMALE SLIDE INSULATED
2
5W001-019
10-12 GA BUTT CONN INSULATED
2
5W001-040
12-10GA FEMALE SLIDE INSULATED
3
5W001-041
12-10GA MALE SLIDE INSULATED
3
5W001-043
12-10GA X 1/4" RING TERMINAL
2
7E010-048
#10 X 3/4 SHEET METAL PHILLIPS
4
8F101-200
RELAY WIRING ASSY
1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit.
Report any shortages or damaged parts immediately.
5A102-033 - FPB ASSY, NON-PRG, HOBBS, UNIV.
PART NO.
DESCRIPTION
QTY
007128
INSTR, UNIV. FPVB UPGRADE
1
008601
BOX, CARDBOARD, PUMP BOOSTR
1
008602
INSERT, CARDBOARD, PUMP BOOSTR
1
5A002-030
VOLT BOOSTER, STD VORT
1
5W001-012
18-22 GA BUTT CONN RED INSUL
1
5W001-019
10-12 GA BUTT CONN INSULATED
2
5W001-042
12-10GA X 3/16" RING TERMINAL
1
5W001-045
16-14 GA RING TERM .17" HOLE
3
5W016-030
16GA STRD WIRE, BLACK
18 FT
7E010-051
#10 X 1/2 HX FLG SHT MTL SCRW
6
7P125-105
1/8 NPT FEM TO 5/32 BARB
1
7P156-082
5/32 TEE
1
7U030-046
5/32" VACUUM LINE
0.5 FT
7U100-044
TIE WRAP, 4" NYLON
5
8D002-003 SWITCH, PRESSURE, HOBBS NORM CLSD
1
