8-RIB UPGRADE KIT, MOUNTING BRACKET/
IDLER ASSEMBLY
2X 4FQ116-031
7C080-090
W/ WASHER
1X 4FL116-160
4X 4FQ017-061 SPACER
(NOT VISIBLE, LO-
CATED BEHIND ACC
PULLEY)
2X 7C080-200
7J312-000
7F008-021
5X 7A375-375
W/ WASHER
4X 2A017-875-08
4X 2A017-875-29
4FL016-170
