Parts list - 1997-2003 5.4l, Parts list – Vortech 1997-2003 Ford 5.4 F-150/Expedition User Manual
Page 6
P/N: 8N020-130
© 2005 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured.
19SEP05 v1.0 97-03F150PwrClr(8N020-130v1.0)
vi
1997-2003 Ford F-150/Expedition 5.4L
Charge Cooler Upgrade System
Part No. 8N301-300/308
®
ENGINEERING, LLC
PARTS LIST
2A038-295
S/C PULLEY 2.95" 8-GRV
1
4FM212-010
DISCHARGE ASY, '99-'03 5.4 F-150
1
4FM112-015
DISCHARGE TUBE “A”, F-150 H.O.
1
4FM012-016
DISCHARGE TUBE “B”, F-150 H.O.
1
7S275-200
SLEEVE, Ø2.75" x 2.00"L, BLUE
2
7S300-200
SLEEVE, 3" x 2", BLUE
2
7U034-016
1" GS HEATER HOSE
.5'
7U034-016
1" GS HEATER HOSE
1.0'
7R002-044
#44 SAE TYPE “F” SS HOSE CLAMP
4
7R002-048
#48 SAE TYPE “F” SS HOSE CLAMP
4
8N055-050
PLASTIC CAP, SURGE TANK
1
7R002-016
#16 SS HOSE CLAMP
4
7U030-046
5/32" VACUUM LINE
2'
7P156-082
5/32" TEE
1
8D001-001
STD COMPRESS BYPASS VALVE
1
8N105-180
WATER TANK/COOLER ASY, '99-'03
1
8N055-030
TANK, WATER TRIANGLE SHAPE
1
7R007-001
NYLON RATCHET CLAMP, 1-1/8"
10
4FM010-180
BRKT, TRIANGLE RES, F-150 H.O.
1
7P500-026
1/2"NPT x 3/4" BARB, 90° BRASS
6
8N006-010
WATER COOLER, SETRAB SINGLE PAS
1
4FM010-190
BRKT, SETRAB UPPER, F-150 H.O.
2
4FM010-170
BRKT, SETRAB LOSER, F-150 H.O.
1
7E010-049
#10 x 3/4" HEX HD SLF DRL SHT MTL
5
7A250-049
1/4-20 x .75" SHCS PLTD
8
7F250-021
1/4-20 NYLOCK NUT, ZINC PLATED
5
7J250-022
1/4" WASHER SAE STAINLESS
15
7U038-000
3/4" HEATER HOSE
15'
7U038-012
HOSE, Ø3/4" x 90°, 4" x 12" LEGS
2
7P375-075
3/4" HOSE BARB UNION, BRASS
1
7J010-001
#10 FLAT WASHER
5
7U100-055
TIE-WRAP, 7.5" NYLON
10
8N107-180
WATER PUMP ASY, 5.4 H.O.
1
5W014-010
14GA STRD WIRE, RED UL1015
8'
5W001-009
16-14GA MAKE SLIDE, INSULATED
2
5W001-010
16-14GA, FEMALE SLIDE, INSULATED
2
5W001-011
16-14GA RING TERM, .26" HOLE
1
5W014-030
14GA STRD WIRE, BLACK
5'
5W001-032
1/4" PLASTIC WIRE LOOM
5"
5W001-041
12-10GA, MALE SLIDE, INSULATED
1
5W001-022
T-TAP CONN, 14-16 AWG
1
5W001-054
16GA FUSE HOLDER WITH WIRE
1
5W001-013
14-16GA BUTT CONN, BLUE, INSULATED
2
5W001-015
FUSE, BLADE TYPE, 20AMP
1
7U100-055
TIE-WRAP, 7.5" NYLON
8
8F001-402
PUMP, WATER, PIERBURG
1
7R003-027
ADEL CLAMP, 1-11/16"
1
8N201-310
WELDED CORE ASY, 5.4 H.O.
1
8N003-030
COOLER DUCT, LT1, GROUND
1
8N030-070
DUCT, COOLER OUTLET, LS1 FBODY
1
8N201-001
WELDED CORE ASSY w/ENDS, S2K
1
8R101-002
PULLEY RETAINER ASSY, 8-RIB
1
2A040-011
PULLEY RETAINER, S/C
1
7B375-125
3/8-24 x 1-1/4" HXHD GR8
7K375-040
3/8"AN960 FLAT WASHER, PLATED
1
7U100-070
KEY, 3/16"SQUARE x 7/8"LONG
1
6Z170-020
8:1 RING SPACER ASSY
1
6Z050-191
FMU WASHER, 8:1 PLATED
1
6Z070-030
FMU 8:1 RING SPACER
1
6Z020-140
LRG DIAPHRAGM, FLOURO
1
007032
FMU RECALIBRATION INSTRUCTIONS
1
6Z170-020
RING AND SPACER, 8:1 FMU
1
2A048-795
8-RIB BELT
1
PART NUMBER DESCRIPTION QTY
