Appendix a-3 – Vortech 1999-2001 Ford 5.4L/6.8L Super Duty/SUV User Manual
Page 32
P/N: 4FT020-010
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
02AUG04 v2.1(99-03SuperDuty(4FT v2.1))
20
Fig. A-3
SP
ACER, SPRING
TENSIONER (NOTE
ORIENT
A
TION)
BRACKET WIRING HARNESS
(NOTE: BRACKET IS MOUNTED
BEHIND PLA
TE)
8-RIB IDLER
GROOVED
MOUNTING
PLA
TE
SUPPOR
T
PLA
TE
(MOUNT ON
TOP OF
MOUNTING
PLA
TE)
APPENDIX A-3
