www.velodyne.com 16 - Optimum Series User’s Manual
SPECIFICATIONS
Model Optimum-8 Optimum-10 Optimum-12
Woofer 8” forward firing
6.5” piston diameter)
10” forward firing
(8” piston diameter)
12” forward firing
(9.7” piston diameter)
Amplifier: Class D 2400 watts Dynamic
1200 watts RMS Power
2400 watts Dynamic
1200 watts RMS Power
2400 watts Dynamic
1200 watts RMS Power
High Pass Crossover: 80Hz (6 dB/octave) 80Hz (6 dB/octave) 80Hz (6 dB/octave)
Low Pass Crossover*: 40-135 Hz
*12 dB octave initial, 24 dB octave
ultimate
40-135 Hz
*12 dB octave initial, 24 dB octave
ultimate
40-135 Hz
*12 dB octave initial, 24 dB octave
ultimate
Frequency Response:
Overall
(+/-3 dB)
16-240Hz
26-135Hz 13-240Hz
23-135Hz 13-240Hz
21-135Hz
Harmonic Distortion: <5% (typical) <5% (typical) <5% (typical)
Magnet Structure 204 oz. (12.7 lbs) 346 oz. (21.6 lbs.) 346 oz. (21.6 lbs.)
Voice Coil: 2.5” Dual Layer inner/outer wind 3” Dual Layer inner/outer wind 3” Dual Layer inner/outer wind
Inputs: Line and Speaker Level Line and Speaker Level Line and Speaker Level
Outputs Line-level, 80Hz up Line-level, 80Hz up Line-level, 80Hz up
Phase: 0°, 90°, 180°, 270° degrees 0°, 90°, 180°, 270° degrees 0°, 90°, 180°, 270° degrees
Video Shielded: No Yes Yes
Dimensions (H/W/D): (inc. feet,
grill and knobs) 11.2” x 10.7” x 14”
(28.4 x 27.2 x 35.6 cm)
13.5” x 13” x 15.4”
(34.3 x 33 x 39 cm)
15.5” x 15” x 18.5”
(39.4 x 38 x 47 cm)
Cabinet: Sealed enclosure Sealed enclosure Sealed enclosure
Finish: Hand-rubbed black lacquer
or cherry veneer
Hand-rubbed black lacquer
or cherry veneer
Hand-rubbed black lacquer
or cherry veneer
Accessories: Mic, mic stand, and remote control Mic, mic stand, and remote control Mic, mic stand, and remote control
Warranty (North America) Three years (electronics)
Five years (drivers)
Three years (electronics)
Five years (drivers)
Three years (electronics)
Five years (drivers)
Warranty (North America) Three years (electronics-parts and labor)
Five years (drivers-parts and labor)
Three years (electronics-parts and labor)
Five years (drivers-parts and labor)
Three years (electronics-parts and labor)
Five years (drivers-parts and labor)
Shipping Weight (approx.) 33 lbs. (15 Kg) 43 lbs. (20 Kg) 49 lbs. (22 Kg)
Specifications are subject to change without notice.
