SPECIFICATIONS
Specifications MicroVee
Driver 6.5” forward firing
(5” piston diameter)
Passive Radiators Dual 6.5” side-firing
(5” piston diameter)
Amplifier (Class D) 2000 watts Dynamic
1000 watts RMS power
Low-Pass Crossover 50 Hz - 200 Hz (adjustable)
12 dB octave initial,
48 dB octave ultimate
Auto On/Off Yes
Cone Anodized aluminum
Frequency Response 38 - 120 Hz (+/-3 dB)
Harmonic Distortion <5% (typical)
Magnet Structure 64 oz.
(4 lbs)
Voice Coil 2” Dual Layer
Inputs Speaker-level, mini-jack and gold plated line-level
Outputs Speaker-level (120 Hz high-pass crossover), mini-jack (thru)
Phase 0° or 180° (selectable)
Video Shielded No
Dimensions (H/W/D) (includes grille) 9” x 9” x 9.6” (22.9 x 22.9 x 24.4 cm)
Cabinet Sealed enclosure
Warranty (parts/labor) Three years (electronics - parts and labor),
Five years (drivers - parts and labor)
Shipping Weight (approx) 20 lbs. (9.1 Kgs)
Specifications are subject to change without notice.
