Velodyne Digital DrivePLUSSeries - Manual (Page 41)

Model DD-10+ DD-12+ DD-15+ DD-18+
Driver 10” forward firing 12” forward firing 15” forward firing 18” forward firing
Amplifier Class D 3000 watts Dynamic
1250 watts RMS Power
3000 watts Dynamic
1250 watts RMS Power
3000 watts Dynamic
1250 watts RMS Power
3000 watts Dynamic
1250 watts RMS Power
Frequency Response
Overall (+/- 3dB)
10.5 - 300 Hz
18.7 - 120 Hz
10.2 - 300 Hz
17 - 120 Hz
9.0 - 300 Hz
14.6 - 120 Hz
8.8 - 300 Hz
14.4 - 120 Hz
THD <1% (typical) <1% (typical) <1% (typical) <1% (typical)
High Pass Crossover 80 or 100 Hz at 6 dB/
octave
80 or 100 Hz at 6 dB/
octave
80 or 100 Hz at 6 dB/
octave
80 or 100 Hz at 6 dB/
octave
Low Pass Crossover 40 Hz to 199 Hz (variable
in 1 Hz increments)
selectable slope
Default: 80 Hz @ 24 dB/
octave
40 Hz to 199 Hz (variable
in 1 Hz increments)
selectable slope
Default: 80 Hz @ 24 dB/
octave
40 Hz to 199 Hz (variable
in 1 Hz increments)
selectable slope
Default: 80 Hz @ 24 dB/
octave
40 Hz to 199 Hz (variable
in 1 Hz increments)
selectable slope
Default: 80 Hz @ 24 dB/
octave
Phase 0 to 180 degress (variable
in 15 degree increments)
0 to 180 degress (variable
in 15 degree increments)
0 to 180 degress (variable
in 15 degree increments)
0 to 180 degress (variable
in 15 degree increments)
Polarity Adjustable (+/-) Adjustable (+/-) Adjustable (+/-) Adjustable (+/-)
Magnet Structure 35 lbs. 35 lbs. 39.7 lbs. 39.7 lbs.
Voice Coil Six-layer, 65mm Six-layer, 65mm Six-layer, 75mm Six-layer, 75mm
Cone Fiberglass Rohacell
Laminate
Fiberglass Rohacell
Laminate
Fiberglass Rohacell
Laminate
Fiberglass Rohacell
Laminate
INPUTS
LFE (Mono)
Line level (RCA),
Nominal Impedance 47K,
Balanced (XLR),
Nominal Impedance 10K
Line level (RCA),
Nominal Impedance 47K,
Balanced (XLR),
Nominal Impedance 10K
Line level (RCA),
Nominal Impedance 47K,
Balanced (XLR),
Nominal Impedance 10K
Line level (RCA),
Nominal Impedance 47K,
Balanced (XLR),
Nominal Impedance 10K
Input (L & R) Line level (RCA & XLR) Line level (RCA & XLR) Line level (RCA & XLR) Line level (RCA & XLR)
Microphone Balanced (Mini-XLR, cable
included)
Balanced (Mini-XLR, cable
included)
Balanced (Mini-XLR, cable
included)
Balanced (Mini-XLR, cable
included)
Speaker Level (L & R) Bare wire, banana plugs,
or spade lugs
Bare wire, banana plugs,
or spade lugs
Bare wire, banana plugs,
or spade lugs
Bare wire, banana plugs,
or spade lugs
OUTPUTS
Thru (L & R)
Line Level (RCA & XLR) Line Level (RCA & XLR) Line Level (RCA & XLR) Line Level (RCA & XLR)
Output (L & R), High -Pass Line Level (RCA & XLR) Line Level (RCA & XLR) Line Level (RCA & XLR) Line Level (RCA & XLR)
Included Accessories Full feature remote control,
DD+ accessory kit and
video cable
Full feature remote control,
DD+ accessory kit and
video cable
Full feature remote control,
DD+ accessory kit and
video cable
Full feature remote control,
DD+ accessory kit and
video cable
Finishes Black gloss ebony, satin
cherry or walnut
Black gloss ebony, satin
cherry or walnut
Black gloss ebony, satin
cherry or walnut
Black gloss ebony, satin
cherry or walnut
Dimensions (H/W/D)
(includes feed and
connectors)
14.2” x 13” x 16.5” 25.8” x 14.4” x18” 20” x 18.1” x 22.5” 22.7” x 20.7” x 25.6”
Shipping Weight (approx) 75 lbs. 85 lbs. 120 lbs. 142 lbs.
Warranty (parts/labor) Two years (electronics)
Two years (drivers)
Two years (electronics)
Two years (drivers)
Two years (electronics)
Two years (drivers)
Two years (electronics)
Two years (drivers)
SPECIFICATIONS
[ 38 ]
