Connect with Dual Connections into a Single System
To use the Digital Drive PLUS dual inputs to make dual connections for a single system:
1) Connect the speaker-level inputs as shown in the Connect section. Be sure to connect + to + and – to –.
2) Connect the LFE signal to the subwoofer’s RCA LFE input connector.
3) In the receiver, set the bass management options to “large” or “full range front left and right speakers.” If the receiver
has an option to add LFE to those channels, select this option as well.
4) Turn the subwoofer’s speaker-level control to MIN (knob all the way to the left).
5) Turn the subwoofer’s line-level control to MAX (knob all the way to the right).
6) Run the system in your primary mode (surround or 2-channel).
7) Optimize the system using Place & Play, Self-EQ, Auto-EQ PLUS , or Manual-EQ. See how to perform these optimization
procedures in the Optimize section.
8) Run the system in the other mode.
9) Turn the subwoofer’s speaker-level control up until the mid-bass is to your liking.
