46
M5
Display when using the heart rate option
If the heart rate option is activated, the current heart rate is
shown at the top left of the display.
If the heart rate option is activated the indicator arrows
show whether the heart rate is below or above the selected
training zone.
The time, which is also displayed if the heart rate option is
disabled, is now accessed as a function by pressing the
BIKE
button.
Button allocation with the heart rate option
If the heart rate option is activated, the heart rate functions
can be accessed by pressing the TPC (TOTAL/PULSE/CAD)
button.
When the heart rate option is activated, the TPC
(TOTAL/PULSE/CAD) button has the following functions:
TPC (TOTAL/PULSE/CAD)
In function mode:
– Access the heart rate functions
(scroll forwards through the functions)
– Select the heart rate training zone
(press and hold)
In setting mode:
– Scroll in the setting menu (backwards)
– Change the data to be set (decrease)
